1.0-2.0t
Semi Electric Stacker

WARRANTY

SERVICE

DELIVERY

TERMS

SOLUTION
●Capacity: 1.0-2.0t
●Innovative hydraulic system
●Quite stable and well performance
●Option straddle legs and forged forks
●Thickened mast
Performance
●Reliable oil cylinder, wear resistance, good sealing performance and anti-leakage;
●Innovative hydraulic system, high quality and powerful, extended service life;
●Components are decades year experienced, quite stable and well performance;
●Equipped with GEL battery,maintenance-free;
●Quality charger, convenient charging, improve work efficiency;
●Wheels are available in PU and nylon to suit different needs and working conditions;
●Optional straddle legs,forged forks and fork length customized.
Safety
●Charger, switch key and emergency switch are integrated in the panel for convenient operation;
●Equipped with sturdy wire mesh cover,more safety and good vision;
●Thickened mast, legs reinforced with steel to ensure stable load;
●Tested brakes, convenient and flexible braking.
Specification
Load capacity |
kg |
1000 |
1000 |
1000 |
1500 |
1500 |
1500 |
2000 |
Load center |
mm |
500 |
500 |
500 |
400 |
400 |
400 |
400 |
Lifting height |
mm |
1600 |
2500 |
3000 |
1600 |
2500 |
3000 |
1600 |
Length |
mm |
1740 |
||||||
Width |
mm |
760/(1100/1500) |
||||||
Ground clearance |
mm |
25 |
||||||
