1.2-2.0t
Electric Stacker

Performance

●With the four-point low center of gravity design and a high-strength steel frame structure,

the vehicle frame has a large residual load capacity and a long service life.

●Using non-contact proximity switch, it can provides long life and reliable operation .

●H-type mast profile section to provide more stable and rigid performance.

●The battery is reliably fixed and the battery cover is Support by soft materials, so that

the vibration and noise generated during the operation of the vehicle are reduced.

●Pedestrian type use the new design drive system, the drive motor will not accompany the tiller rotation,

it can keep all the cable connect to the drive motor avoid being bent.

●With a low noise and low vibration hydraulic power unit to enable stable and reliable lifting and descending.

Specifications

Drive type

Electric

Electric

Electric

Electric

Operation type

Pedestrian

Pedestrian

Pedestrian

Pedestrian

Rated capacity

kg

1200

1400

1600

2000

Load centre

c (mm)

600

600

600

600

Wheelbase

y (mm)

1318

1318

1318

1318

Wheels, number front/rear (× = driven wheels)

1X+1/4

1X+1/4

1X+1/4

1X+1/4

Lift

h3 (mm)

2700

2700

2700

2700

Height, lowered

h13 (mm)

90

90

90

90

Overall length

l1 (mm)

1934

1934

1934

1934

Overall width

b1/b2 (mm)

800

800

800

800

Travel speed

km/h

6/6

6/6

6/6

6/6

Lift speed

m/s

0.225/0.47

0.195/0.4

0.18/0.4

0.16/0.34

Drive motor

kW

2.2

2.2

2.2

2.2

Lift motor

kW

4.2

4.2

4.2

4.2

Battery

V/Ah

48/105

48/105

48/105

48/105
