2.0t
Rough Terrain Electric Stacker

Performance

●Equipped with rubber solid tires, it easily conquers uneven terrain;

●Specially designed for rough surfaces, allowing easy operation on complex terrains such as construction sites;

●High ground clearance, offers superior passing ability over uneven surfaces;

●Three-point support with straddle legs, provides enhanced stability and strong adaptability to various pallet

specifications.

Operation

●Long handle design, features extended handle for effortless operation and highly flexible steering;

●Wide mast with unobstructed vision, ensures safe and flexible operation by maximizing visibility;

Safety

●Metal mesh on mast, acts as a protective barrier, isolating and safeguarding the operator;

●Load-backrest, prevents cargo from falling during handling operations;

●Forged forks offer high load-bearing capacity, remain undeformed under heavy loads, and steadily lift pallets.

Maintenance

●External charger, acilitates centralized management and easy maintenance;

●Reliable controller with low failure rate that minimizes malfunctions, effectively extending the service life.

Specifications

Power type

full electric

Operation

Pedestrian

Capacity

Q(kg)

2000

Loading center

C(mm)

500

Lifting height

h3(mm)

1600

Overall length

l1 (mm)

1765

Overall width

b1(mm)

1615

Travel speed, laden/unladen

km/h

3.6~4

Lifting speed, laden/unladen

m/s

0.08/0.10

Lowering speed, laden/ unladen

m/s

0.12/0.10

Gradeability, laden/unladen

%

8/15
