2.0-3.0t Heavy-duty Ride-on Pallet Truck

2.0-3.0t
Heavy-duty Ride-on Pallet Truck

We provide
WARRANTY

We guarantee
SERVICE

Fast
DELIVERY

Transparent
TERMS

Customized
SOLUTION

●Capacity：2.0-3.0t

●Precise power steering

●High travelling speed

●Strong heavy load capacity

●Standing operation is suitable for long-distance transportation.

Performance

●Using slider motion structure and one-time full-axis processing technology to ensure higher working

accuracy

●Adopting special pin material, heat treatment process and customized sleeve to increase

lifetime of movable parts. And makes truck durable.

Operation

●Equipped with platform for easy operation and improved working efficiency.

Safety

●The side arms are produced from strengthened steel to keep the operator in safe while fast driving.

●Automatically decelerate when turning

Maintenance

●Add maintenance-free parts and easily disassembled parts for easy maintenance in future.

Specifications

Power type		full electric	full electric	full electric
Operation		Standing	Standing	Standing
Capacity	Q(kg)	2000	2500	3000
Loading center	C(mm)	600	600	600
Lifting height	h3 (mm)	120	120	120
Height handle in driving position min./max.	h14 (mm)	1075/1290	1075/1290	1075/1290
Overall length	l1 (mm)	1954	1954	1954
Length to face of fork	l2 (mm)	804	824	824
Overall width	b1/b2 (mm)	734	734	734
Travel speed, laden/unladen	km/h	7.5/8	5.5/6	5.5/6
Lifting speed, laden/unladen	m/s	0.05/0.054	0.05/0.054	0.05/0.054
Lowering speed, laden/ unladen	m/s	0.067/0.054	0.067/0.054	0.067/0.054
Gradeability, laden/unladen	%	8/16	6/16	6/16
