3.0-3.8tHigh Voltage Electric Forklift

Performance

●CATL 309V high voltage lithium battery enable the forklift with fast lifting speed, fast driving

speed and great gradeability;

●Equipped with 1C super charger, it can be charged to 80% in 30 minutes and fully charged

within one hour, with high efficiency;

●PMSM system, better energy saving and extended working time;

●The powerful performance exceeds internal combustion forklifts of the same tonnage

and no pollution, less noise.

Operation

●Ergonomic design, wide field of view, adjustable steering wheel and seat, heightening of overhead

guard, reducing driving fatigue and make operator comfortable;

●High ground clearance, high passability, suitable for working on different road surfaces. It can

work in high temperature, cold, high altitude and high dust environment;

●Side shift, fork positioner and other accessories are available to install on the forklift to improve

the working efficiency;

●Option OPS, the driver leaves the seat and the vehicle cannot be operated, avoiding accidents.

Safety

●Multiple insulation tests，safe and stable operation of the power system;

●Overload protection to ensure the safety of operators and goods;

●Reversing reminder, reminding people around to avoid and prevent accidents;

●The wide-view mast design provides the drivers with an excellent field of vision, more safety.

Maintenance

●IP67 waterproof, suitable for different working conditions, extending service life;

●Maintenance-free AC motor and lithium battery, less maintenance cost;

●Integrated distribution of electrical components for easy inspection and maintenance;

●Optional mast,side shift, fork positioner and multiple attachments are available.

Specifications

Power type		full electric	full electric	full electric
Operation		Seated	Seated	Seated
Capacity	Kg	3000	3500	3800
Load center	mm	500	500	500
Lifting height	mm	3000	3000	3000
Overall length	mm	3811	3866	3891
Length to face of fork	mm	2741	2796	2821
Overall width	mm	1224	1224	1224
Travel speed (laden/unladen)	Km/h	16/18	16/18	16/18
Lifing speed (laden/unladen)	mm/s	520/530	430/440	430/440
Lowering speed (laden/unladen)	mm/s	≤600/≥300	≤600/≥300	≤600/≥300
Max.Gradeability (laden)	%	20	20	20
