Aluminum Lift Platform

Performance

●Lightweight: Aluminum is significantly lighter than steel, making the platforms easier to transport and maneuver；

●Corrosion Resistance: Aluminum naturally resists rust and corrosion, ensuring long-term durability

in various environments；

●Low Maintenance: Aluminum platforms require less maintenance;

●Recyclability: Aluminum is 100% recyclable, contributing to environmental sustainability；

●Easy Assembly: designed for quick and straight forward setup；

●Versatility: Suitable for both indoor and outdoor use across a wide range of industries；

●Optional mast to meet different height needs;

●Optional traction motor, can be pulled for labor-saving and improving work efficiency.

Specifications

Mast

Maximum platform height（m）

Maximum operating height(m)

Capacity(kg)

Platform dimension(m)

Single

4

5.7

150

0.64*0.58

Single

8

9.7

150

0.64*0.58

Single

10

11.7

125

0.64*0.58

Two-stage

6

7.7

300

1.10*0.6

Two-stage

10

11.7

300

1.32*0.6

Two-stage

14

15.7

200

1.42*0.6

Three-stage

13

14.7

250

1.56*0.8

Three-stage

15

16.7

250

1.56*0.85

Four-stage

14

15.7

250

1.56*0.85

Four-stage

18

19.7

250

1.6*0.85

Six-stage

18

19.7

150

1.36*0.9

Six-stage

24

25.7

150

1.36*0.9
