CPC(D) 2-3.5t
Diesel/Gasoline/LPG
WARRANTY
SERVICE
DELIVERY
TERMS
SOLUTION
●Capacity:2-3.5t
●Power type:Diesel/Gasoline/LPG
●Low power consumption, long life and adaptable to a wide temperature range, strong anti-interference ability
Performance
●Built in intelligent chip, working sensitively, correctly, and reliably;
●The cover is equipped with heat-insulating and sound absorbing materials. Cover and body are connected, by filling, sealing and blocking rubber components at the gap to absorption vibration and reduced the noise;
Operation
●Ergonomic design, shock absorption technology and flexible active synchronizer mechanical transmission control makes the operation of the whole machine more comfortable and steady;
●Can see the speed, fuel consumption, and working hours from display.
Safety
●With working light, rear combination light, mirror, improve a lot in safety;
●Wide field of view, clear working conditions, protecting the safety of operators and goods;
●The overhead guard is integrally formed, which is safer and more sturdy
Maintenance
●Powerful and reliable engine, increasing vehicle life, reducing maintenance,and improving work efficiency;
●A larg engine cover is convenient for inspection and maintenance.
Specifications
Model |
CPC(D)20T3 |
CPC(D)25T3 |
CPC(D)30T3 |
CPC(D)35T3 |
CPC(D)30T3Z |
CPC(D)35T3Z |
|
Power type |
Diesel/Gasoline/LPG |
Diesel/Gasoline/LPG |
Diesel/Gasoline/LPG |
Diesel/Gasoline/LPG |
Diesel |
Diesel |
|
Operation |
Seated |
Seated |
Seated |
Seated |
Seated |
Seated |
|
Capacity |
Kg |
2000 |
2500 |
3000 |
3500 |
3000 |
3500 |
Load center |
mm |
500 |
500 |
500 |
500 |
500 |
500 |
Lifting height |
B (mm) |
3000 |
3000 |
3000 |
3000 |
3000 |
3000 |
Overall length |
Z (mm) |
3580 |
3650 |
3780 |
3830 |
3935 |
3830 |
Length to face of fork |
Y (mm) |
2510 |
2580 |
2710 |
2760 |
2865 |
2865 |
Overall width |
Q (mm) |
1150 |
1150 |
1230 |
1230 |
1230 |
1230 |
Overhead guard height |
P (mm) |
2160 |
2160 |
2190 |
2190 |
2190 |
2190 |
Travel speed (laden/unladen) |
Km/h |
19.5/20 |
19.5/20 |
19.5/20 |
19.5/20 |
19.5/20 |
19.5/20 |
Lifing speed (laden/unladen) |
mm/s |
450/500 |
450/500 |
470/520 |
460/510 |
480/500 |
480/500 |
Lowering speed (laden/unladen) |
mm/s |
400/380 |
400/380 |
400/380 |
400/380 |
400/380 |
400/380 |
Max.Drawbar pull (laden) |
N |
14000 |
14500 |
21000 |
21000 |
21000 |
22000 |
Max.Gradeability (laden) |
% |
20 |
20 |
20 |
20 |
20 |
20 |
