CPD15FJ5/CPD20FJ5

Performance

●Lifting overload protection, hydraulic system explosion-proof design, even if the oil pipe bursts,

the mast will not fall quickly;

●Regenerative braking and anti-skid slope, stable operation.

●The cover is equipped with heat-insulating and sound absorbing materials. Cover and body are connected, by filling,

sealing and blocking rubber components at the gap to absorption vibration and reduced the noise;

Operation

●Optimized layout of brake and accelerator pedals, more flexible and comfortable operation;

●The seat is adjustable to suit different operators, making it more comfortable and safety

Safety

●Emergency power-off switch can easily cut off all power supply while out of control to ensure safety;

●Sturdy roof protection design improving safety;

●Low pedals are equipped with safety handrails, which fully consider the humanized requirements;

Maintenance

●Automatic low voltage protection to extend battery life;

●Imported AMP waterproof and dustproof connectors, improve service life;

●Controller self-diagnostic system;

●Side shifter, mast and cabin are optional.

Specifications

Model

CPD15FJ5

CPD20FJ5

Power type

full electric

full electric

Operation

Steated

Steated

Capacity

Q(kg)

1500

2000

Loading center

C(mm)

500

500

Lifting height

h3 (mm)

3000

3000

Overall length

l1 (mm)

3085

3200

Length to face of fork

l2 (mm)

2165

2280

Overall width

b1/b2 (mm)

1080/1070

1080/1070

Travel speed, laden/unladen

km/h

12/12.5

12/12.5

Lifting speed, laden/unladen

m/s

0.25/0.45

0.25/0.45

Lowering speed, laden/ unladen

m/s

0.45/0.44

0.45/0.44

Gradeability, laden/unladen

%

10.5/14

10.5/14
