CPD15-20TVL
3-Wheel Electric Forklift

Performance

●Lifting limit switch, which makes the mast more stable at high position;

●80V lithium battery for long working time,increased efficiency.

Operation

●More compact, small turning radius, and it is an ideal tool for carrying goods through narrow aisle;

●Driving space optimized, and there is more room for foot operation;

●Excellent ergonomics with adjustable steering wheel and comfortable bucket seat.

Safety

●High-strength mast provides optimal all-round visibility and excellent stability, and will not

shake even when fully loaded, more safety.

Maintenance

●Modular design, good quality and easy maintenance;

●Mature components,increase service life;

●Equipped with new smart instrument that can display power,speed and vehicle status.

Specifications

Model

CPD15TVL

CPD18TVL

CPD20TVL

Power type

full electric

full electric

full electric

Operation

Steated

Steated

Steated

Capacity

Q(kg)

1500

1800

2000

Loading center

C(mm)

500

500

500

Lifting height

h3 (mm)

3000

3000

3000

Overall length

l1 (mm)

2733

2833

3020

Length to face of fork

l2 (mm)

1813

1913

1950

Overall width

b1/b2 (mm)

1070

1070

1170

Travel speed, laden/unladen

km/h

13/14

13/14

13/14

Lifting speed, laden/unladen

m/s

0.33/0.45

0.33/0.45

0.33/0.45

Lowering speed, laden/ unladen

m/s

0.4/0.44

0.4/0.44

0.4/0.44

Gradeability, laden/unladen

%

10/15

10/15

10/15
