CPD25-35F8

Performance

●Pneumatic tires has a great performance on adsorb vibration;

●Emergency power-off switch to easily cut off all power supplies when the operation is out of

control to avoid accidents;

●The headguard adopts a specially customized tube design, which is safe and beautiful.

Operation

●Seat switch to prevent misoperation such as walking and lifting;

●Lower pedals are equipped with safety handrails, which fully consider the humanized requirements;

●The steering wheel is adjustable, the driving space is large, the brake and accelerator pedals are optimized,

brings a new driving experience.

Safety

●Regenerative brake and anti-roll back in slope ensure safety operation；

●Lifting overload protection and explosion-proof design of the hydraulic system. Even if the oil

pipe bursts, the mast will not drop quickly,improving safety.

Maintenance

●Automatic low-voltage protection to extend battery life;

●By opening the cover,can check the controller,hydraulic motor, pump and other major components,

which is convenient for maintenance;

●AMP waterproof and dustproof connectors.

Specifications

Model

CPD25F8

CPD30F8

CPD35F8

Power type

full electric

full electric

full electric

Operation

Steated

Steated

Steated

Capacity

Q(kg)

2500

3000

3500

Loading center

C(mm)

500

500

500

Lifting height

h3 (mm)

3000

3000

3000

Overall length

l1 (mm)

3416

3620

3620

Length to face of fork

l2 (mm)

2346

2550

2550

Overall width

b1/b2 (mm)

2346

1220

1220

Travel speed, laden/unladen

km/h

13/ 13.5

11/ 12

11/ 12

Lifting speed, laden/unladen

m/s

0.3/ 0.45

0.23/ 0.37

0.23/ 0.37

Lowering speed, laden/ unladen

m/s

0.44/ 0.435

0.50/ 0.48

0.50/ 0.48

Drawbar pull, laden/unladen

N

17000

18000

18000

Gradeability, laden/unladen

%

10.5/14

10.5/14

10.5/14
