CPD45F8/CPD50F8
WARRANTY
SERVICE
DELIVERY
TERMS
SOLUTION
●Capacity：4.5/5t ●Suitable for indoor and outdoor ●Big solid rubber tyres
Performance
●Emergency power-off switch can easily cut off all power supplies when the operation is out of
control to avoid emergency accidents;
●Automatic low voltage protection to extend the battery life;
●Lifting overload protection, hydraulic system explosion-proof design, even if the oil pipe bursts,
the mast will not drop quickly.
Operation
●Ergonomic design, large leg room, adjustable steering wheel, comfortable bucket seat;
●The comfortable bucket seat height is just 1205mm from the ground, easy access and exit;
●Intelligent instrument that can display system information such as power, usage time and error codes.
Safety
●Big solid rubber tyres, more stable and wear-resistant, can run smoothly even on uneven
roads, suitable for a variety of working conditions;
●Regenerative braking, slope anti-skid, to ensure driving safety.
Maintenance
●Drive motor, pump motor, and brake pedal are arranged reasonably, the line and oil pipe are
optimized, and the pedal is easy to open, making the inspection, maintenance, and replacement of parts
more convenient;
●AMP waterproof and dustproof connector.
Specifications
Model |
CPD45F8 |
CPD50F8 |
|
Power type |
full electric |
full electric |
|
Operation |
Steated |
Steated |
|
Capacity |
Q(kg) |
4500 |
4999 |
Loading center |
C(mm) |
500 |
500 |
Lifting height |
h3 (mm) |
3000 |
3000 |
Height of overhead guard |
h6 (mm) |
2353 |
2353 |
Overall length |
l1 (mm) |
4027 |
4035 |
Length to face of fork |
l2 (mm) |
2958 |
2965 |
Overall width |
b1/b2 (mm) |
1479 |
1600 |
Travel speed, laden/unladen |
km/h |
14/14.5 |
14/14.5 |
Lifting speed, laden/unladen |
m/s |
0.26/0.45 |
0.26/0.45 |
Lowering speed, laden/ unladen |
m/s |
0.55/0.5 |
0.55/0.5 |
Drawbar pull, laden/unladen |
N |
26000 |
26000 |
Gradeability, laden/unladen |
% |
14/15 |
14/15 |
