CPD50L1

Performance

●Speed increased to 16/18km/h to meet warehouse operation needs and improve transportation efficiency；

●Reliable hydraulic system, more precise and quiet lifting；

●IP65 external plug, easy to charge without opening the cover.

Operation

●The overhead guard height of  2250mm and the mast is specifically designed for container；

●Small turning radius provide maneuverability in narrow spaces；

●Ergonomic design, spacious legroom and adjustable steering wheel, more comfortable.

Safety

●Strengthened structure, firm and reliable, ensuring the safety of operators and goods；

●Equipped with emergency switches to prevent accidents in emergency situations；

●Optional OPS system,automatically locked when leaving the seat, more safety；

●Optional cabin to meet different weather conditions,safety operation.

Maintenance

●Solid tires are more wear-resistant and firm, extending service life,optional with non-marking tire；

●Lithium battery,maintenance-free；

●Reliable components,reduce maintenance cost and improve the working efficiency.

Specifications

Model

CPD50L1

Power type

full electric

Operation

Seated

Capacity

Q(kg)

5000

Loading center

C(mm)

500

Lifting height

h3 (mm)

3000

Height of overhead guard

h6 (mm)

2250

Overall length

l1 (mm)

3970

Length to face of fork

l2 (mm)

2900

Overall width

b1/b2 (mm)

1550

Travel speed, laden/unladen

km/h

16/18

Lifting speed, laden/unladen

m/s

0.3/0.46

Lowering speed, laden/ unladen

m/s

0.45/0.51

Drawbar pull, laden/unladen

N

26000

Gradeability, laden/unladen

%

15/20
