CQD15SD
WARRANTY
SERVICE
DELIVERY
TERMS
SOLUTION
●Capacity：1.5t ●Electric Pantograph Reach Truck ●Suitable for high-level stacking
Performance
●Double scissor forward type reach truck could save a lot warehouse space;
●Enhanced mast, increased stability, maximum lifting height up to 11.5m, full loading capacity
up to 8.15m. Makes the vehicle is the best choice for high-level stacking;
●Oil pumps, cylinders and pipelines that have undergone multiple tests , ensuring high
reliability of the hydraulic system；
●Lead-acid and lithium battery is optional for different needs;
●AC driving motor with continuous power, enable the machine to work with heavy-duty condition
and long working time.
Operation
●Electronic steering, flexible and convenient operation;
●Control panel fully considers ergonomics, and each function button is easy to operate;
●The battery is easy to pull out and replace, ensuring continuous operation;
●The machine equipped height selection and a multifunctional control handle, including
proportional lifting, fork movements, mast tilting,and side shifting. This enables more convenient,
precise and gentle operation with stepless speed regulation. Additionally, the optional 1080P camera
positioned at the fork side provides clear real-time surveillance, further improving visibility and safety
for operation.
Safety
●Reliable braking system, electromagnetic brake,protects drivers and cargo;
●Emergency power-off switch can easily cut off all power supplies to avoid emergencies;
●Explosion-proof hydraulic system,even if the oil pipe bursts, the mast will not drop quickly;
●Equipped with overhead guard to protect the operator’s safety.
Maintenance
●LCD display with hour meter and power display,remind to charge in time，and can monitor the
whole vehicle status;
●Maintenance-free AC motor，reduces maintenance costs;
●Most electrical components are centralized distribution,making maintenance more convenient.
Specifications
Model |
CQD15SD |
|
Power type |
full electric |
|
Operation |
Standing |
|
Capacity |
Q(kg) |
1500 |
Loading center |
C(mm) |
600 |
Lifting height |
h3 (mm) |
3000② |
Height of overhead guard |
h6 (mm) |
2330 |
Overall length |
l1 (mm) |
2790 |
Length to face of fork |
l2 (mm) |
1717 |
Overall width |
b1/b2 (mm) |
1078/1148 |
Travel speed, laden/unladen |
km/h |
11/12 |
Lifting speed, laden/unladen |
m/s |
0.45/0.5 |
Lowering speed, laden/ unladen |
m/s |
0.5/0.5 |
Reaching speed, laden /unladen |
m/s |
0.2/0.23 |
Gradeability, laden/unladen |
% |
10/12 |
