CQD16-25RV(F)2

Performance

●Equipped with height indicator, operators can see the correct height of the fork at different

shelf levels for precise operations；

●Color display,allows the driver to monitor driving speed, battery status, and error codes；

●Powerful performance and quiet operation through the upgraded hydraulic pump and

reduces operation noise.

Operation

●Control panel fully considers ergonomics, making operation more comfortable;

●Proportional lifting for precise stacking；

●The maximum lifting height of CQD16RV(F)  is 9.5m,CQD20RV(F)2 is 12 m and CQD25RV(F) reaches lift

heights up to 12.5m.

Safety

●Safety pedal design: the vehicle can be controlled only after the pedal is pressed, and when the pedal

is released can only use hydraulic operation, reducing the risk of incorrect operation；

●Optimize the appearance structure to reduce visual obstruction，more flexible and safety.

Maintenance

●Controller self-diagnosis system, easy maintenance；

●Automatic low voltage protection, extending battery life；

●AC motor with great power and maintenance-free.

Specifications

Model

CQD16RV(F)2

CQD20RV(F)2

CQD25RV(F)

Power type

full electric

full electric

full electric

Operation

Seated

Seated

Seated

Capacity

Q(kg)

1600

2000

2500

Loading center

C(mm)

600

600

600

Lifting height

h3 (mm)

7500

7500

12000③

Height of overhead guard

h6 (mm)

2213

2213

2213

Overall length

l1 (mm)

2515

2515

2586

Length to face of fork

l2 (mm)

1445

1445

1521

Overall width

b1/b2 (mm)

1270

1270

1260/1345

Travel speed, laden/unladen

km/h

10/11

9/9.5

9/9.5

Lifting speed, laden/unladen

m/s

0.35/0.5

0.35/0.45

0.3/0.35

Lowering speed, laden/ unladen

m/s

0.41/0.38

0.41/0.38

0.4/0.3

Reaching speed, laden /unladen

m/s

0.18/0.18

0.18/0.18

0.15/0.15

Gradeability, laden/unladen

%

10/11

10/15

7/14
