CQD16/20L(B)
WARRANTY
SERVICE
DELIVERY
TERMS
SOLUTION
●Capacity：1.5t ●Lithium battery,maintenance-free ●Seated operation，more comfortable ●Suitable for high-shelf stacking
Performance
●Powerful performance and quiet operations through the upgraded hydraulic pumps and
lifting motors. Greatly improves stacking efficiency and reduces noise；
●Offset layout of the oil tubes,stacking visibility and operation flexibility are greatly improved.
Operation
●6000K led lights for optimal visibility, convenient night operation；
●CQD20L is equipped with height indicator, operators can see the correct height of the fork at different shelf
levels for precise operations.
Safety
●Increase the strength of the mast, high stability and more safety；
●BMS management system, overcharge, over discharge and over temperature protection, mature electronic
control system, improved safety；
●Suspension seat design reduces vibration, make driving more safety and comfortable.
Maintenance
●Color display to help operators easily monitor power meter, driving speed and check error codes；
●Lithium battery maintenance-free；
●Reliable components, long service life.
Specifications
Model |
CQD16L |
CQD20L |
CQD20LB CE) |
CQD20LB (NON-CE) |
|
Power type |
full electric |
full electric |
full electric |
full electric |
|
Operation |
Seated |
Seated |
Seated |
Seated |
|
Capacity |
Q(kg) |
1600 |
2000 |
2000 |
2000 |
Loading center |
C(mm) |
600 |
600 |
600 |
600 |
Lifting height |
h3 (mm) |
6500 |
7500 |
9500 |
9500 |
Height of overhead guard |
h6 (mm) |
2153 |
2213 |
2213 |
2213 |
Overall length |
l1 (mm) |
2434 |
2463 |
2443 |
2443 |
Length to face of fork |
l2 (mm) |
1330 |
1393 |
1373 |
1373 |
Overall width |
b1/b2 (mm) |
1090 |
1270 |
1260/1270 |
1260/1270 |
Travel speed, laden/unladen |
km/h |
9/9.3 |
10/11 |
9/9.5 |
9/9.5 |
Lifting speed, laden/unladen |
m/s |
0.35/0.55 |
0.38/0.55 |
0.45/0.55 |
0.45/0.55 |
Lowering speed, laden/ unladen |
m/s |
0.55/0.5 |
0.41/0.38 |
0.5/0.45 |
0.5/0.45 |
Reaching speed, laden /unladen |
m/s |
0.15/0.15 |
0.18/0.18 |
0.15/0.15 |
0.15/0.15 |
Gradeability, laden/unladen |
% |
8/10 |
10/15 |
10/15 |
10/15 |
