CQE12R/CQE15R

Performance

●Low-noise, low-fault hydraulic station, cylinders and pipelines undergo multiple tests

to ensure high reliability of the hydraulic system；

●High-efficiency heat dissipation system for long&continuous operation；

●AC drive system provides strong power.

Operation

●Electronic steering and small size makes it more suitable for use in narrow aisles；

●The handle fully considers ergonomics, and each function button is easy to operate.

Safety

●Solenoid valve power-off locking function；

●Electric steering and automatic deceleration function on curves，more safety；

●Explosion-proof design of the hydraulic,ensure even if the oil pipe bursts, the mast will not drop quickly；

●The emergency reverse driving function and emergency power-off switch protects the operator from injury.

Maintenance

●AMP waterproof connectors and electrical components, all wires and cables are reliably

protected and fixed, greatly reducing electrical failures；

●Automatic low voltage protection to extend battery life；

●Controller self-diagnosis system displays fault codes, making it easier to solve faults.

Specifications

Model

CQE12R

CQE15R

Power type

full electric

full electric

Operation

Standing

Standing

Capacity

Q(kg)

1200

1500

Loading center

C(mm)

500

500

Lifting height

h3 (mm)

3000

3000

Height of overhead guard

h6 (mm)

-

-

Overall length

l1 (mm)

2312

2332

Length to face of fork

l2 (mm)

1242

1262

Overall width

b1/b2 (mm)

850/988

850/1018

Travel speed, laden/unladen

km/h

5.5/6

5.5/6

Lifting speed, laden/unladen

m/s

0.12/0.15

0.12/0.145

Lowering speed, laden/ unladen

m/s

0.18/0.12

0.18/0.12

Reaching speed, laden /unladen

m/s

0.08/0.1

0.07/0.08

Gradeability, laden/unladen

%

6/10

6/10
