DS2

Operation

●Small handle, easy to operate;

●Turtle speed button to walk upright ,more convenient for narrow channel operations;

●Battery display, the battery usage time can be seen;

●Built-in charger, charging is more convenient;

●The handle returns to its original position with a compression spring, more labor-saving.

Safety

●The body is wide and stable, and has fully passed the stability test standards;

●The iron mesh cover of the mast isolates operator and goods to ensure the safety;

●An explosion-proof valve is installed inside the oil cylinder to protect operator safety.

Maintenance

●The handle has malfunction indicator to read the malfunction;

●Sturdy mast and forks ensure the stability of the stacker;

Wide View

●The mast has a single chain structure, and the front view is wide;

●The handle adopts an offset solution, which provides a better operating field of vision.

Specifications

Model

DS2

Power type

full electric

Operation

Pedestrian

Capacity

Q(kg)

1500

Loading center

C(mm)

500

Lift height

h3 (mm)

2530

Overall length

l1 (mm)

1713

length to face of fork

l2 (mm)

560

Overall width

b1/b2(mm)

890

Travel speed, laden/unladen

km/h

3.7/4.0

Lifting speed, laden/unladen

m/s

0.085/0.135

Lowering speed, laden/ unladen

m/s

0.105/0.085

Gradeability, laden/unladen

%

3/10
