DS3

Performance

●Equipped with hour meter and power display to remind to charge in time and protect the battery；

●The hydraulic system is explosion-proof. Even if the oil pipe bursts, the mast will not drop quickly；

●Optional built-in and external charger, to meet various demands from clients.

Operation

●Upright walking function, easy to operate in narrow passages；

●The handle is mechanical spring structure, which is easy to operate and has low failure；

●The lifting system adopts a double chain structure, which makes the lifting more stable and reliable；

●Ergonomical designed handle provide a comfortable experience to operator.

Safety

●The mesh cover is fixed on the mast to isolate and protect the safety of operators and goods；

●The cover is made of fireproof material, safe and reliable；

●Emergency power off switch can cut off all power supply in case of out-of-control to avoid accidents.

Maintenance

●The back cover of the handle has an indicator light, which makes it easy to read faults；

●The hydraulic system and electrical control system，adopt modular installation method to simplify the

oil circuit and line, and facilitate maintenance.

Specifications

Model

DS3

Power type

full electric

Operation

Pedestrian

Capacity

Q(kg)

1500

Loading center

C(mm)

600

Lifting height

h3 (mm)

2930

Height of tiller handle in drive position min./max.

h14 (mm)

760/1140

Lowered height

h13 (mm)

90

Overall length

l1 (mm)

1727

Length to face of fork

l2 (mm)

577

Overall width

b1/b2 (mm)

834

Travel speed, laden/unladen

km/h

4.0/4.5

Lifting speed, laden/unladen

m/s

0.085/0.13

Lowering speed, laden/ unladen

m/s

0.105/0.085

Gradeability, laden/unladen

%

3/10
