ECT061/ECT101

Performance

●Built-in charger, ensure charge on time, improve the working efficiency；

●Reliable hydraulic system, more precise and quiet lifting；

●Counterweight design,suitable for all pallets.

Operation

●Upright walking,more convenient operation in narrow aisle；

●Long handle,it’s easier for operation；

●Lower body height, wide field of view, easy to operate；

●It can also add standing platform as option.

Safety

●Electromagnetic brake,more safety and reliable；

●Emergency power-off button to easily cut off all power when out of control to avoid accidents；

●Strengthen structure, make it more solid and sturdy, and ensure the safety of operators and goods.

Maintenance

●Reasonable layout, easy disassembly and convenient maintenance；

●Imported waterproof connectors to extend service life；

●Maintenance-free battery, more reliable and reducing maintenance cost.

Specifications

Model

ECT061

ECT101

Power type

full electric

full electric

Operation

Pedestrian

Pedestrian

Capacity

Q(kg)

600

1000

Loading center

C(mm)

400

400

Lifting height

h3 (mm)

1600

1600

Overall length

l1 (mm)

1887

2087

Length to face of fork

l2 (mm)

1137

1337

Overall width

b1/b2 (mm)

846

846

Travel speed, laden/unladen

km/h

3.8/4.3

3.8/4.3

Lifting speed, laden/unladen

m/s

0.13/0.2

0.13/0.2

Lowering speed, laden/ unladen

m/s

0.16/0.15

0.16/0.15

Gradeability, laden/unladen

%

5/6

5/6
