EFL151/EFL181/EFL201

Performance

●Fork lowering buffer function, more stable descent, protect the ground and fork from collision damage；

●Lifting overload protection, explosion-proof design of hydraulic system, even if the oil pipe bursts,

the mast will not drop quickly.

Operation

●Steering wheel is adjustable, the driving space is large, and the brake and accelerator pedals are optimally

arranged, making operation convenient and comfortable；

●Small turning radius enable the forklift to work in narrow aisle.

Safety

●LED lights, better and safer vision for night operation；

●Regenerative braking to prevent slipping, avoid accidents and ensure driving safety；

●Optional OPS system, the fork will not drop when the driver leaves the seat；

●Optional light warning system to confirmation of safe driving area convenient.

Maintenance

●Reliable components,and simple layout for easy access to the main components for maintenance；

●Lithium battery, maintenance-free, greatly reducing maintenance costs.

Specifications

Model

EFL151

EFL181

EFL201

Power type

full electric

full electric

full electric

Operation

Seated

Seated

Seated

Capacity

Q(kg)

1500

1800

2000

Loading center

C(mm)

500

500

500

Lifting height

h3 (mm)

3000

3000

3000

Height of overhead guard

h6 (mm)

2080

2080

2080

Seat height/standing height

h7 (mm)

1060

1060

1060

Overall length

l1 (mm)

2935

2935

3314

Length to face of fork

l2 (mm)

2015

2015

2240

Overall width

b1/b2 (mm)

1080

1080

1080

Travel speed, laden/unladen

km/h

8.5/9

8.5/9

11/14

Lifting speed, laden/unladen

m/s

0.25/0.3

0.25/0.3

0.25/0.3

Lowering speed, laden/ unladen

m/s

0.42/0.45

0.42/0.45

0.42/0.45

Max.Drawbar pull  (laden)

N

10000

10000

11000

Gradeability, laden/unladen

%

11/15

11/15

12/15
