EFL252/EFL302/EFL352

Performance

●Comparing to diesel forklift, it saves 30%-50% of energy cost with li-ion technology. More

energy-saving and environmentally friendly;

●Lithium batteries can be charged at any time，will not disrupting working schedules;

●Equipped with parking, emergency power-off and other protections for safe driving;

●Optional weighing system and cabin,etc.

Operation

●The steering wheel is adjustable, suitable for drivers of different body shapes and operating

habits;

●The steering system has been finely tuned, making turns smooth and without lag.

Safety

●Equipped with mechanical braking system,shortens the braking distance to ensure safety;

●Low-voltage lithium battery eliminates the risk of electric shock and leakage;

●Adopt reinforced mast, thicker material, strong load capacity and good comprehensive performance.

Maintenance

●No air filter, oil filter, engine oil or starter battery installed.So,there is no maintenance fee;

●Good ventilation to extend battery life;

●Use mature common components of internal combustion forklift, such as front and rear axles,

lifting hydraulics and operating systems, which are strong and durable.

Specifications

Model

EFL252

EFL302

EFL352

Power type

full electric

full electric

full electric

Operation

Steated

Steated

Steated

Capacity

Q(kg)

2500

3000

3500

Loading center

C(mm)

500

500

500

Lifting height

h3 (mm)

3000

3000

3000

Height of overhead guard

h6 (mm)

2160

2160

2190

Seat height/standing height

h7 (mm)

1095

1130

1130

Overall length

l1 (mm)

3573

3780

3940

Length to face of fork

l2 (mm)

2503

2710

2870

Overall width

b1/b2 (mm)

1154

1230

1230

Travel speed, laden/unladen

km/h

11/12

11/12

11/12

Lifting speed, laden/unladen

m/s

0.28/0.37

0.29/0.36

0.29/0.36

Lowering speed, laden/ unladen

m/s

0.45/0.5

0.4/0.43

0.4/0.43

Gradeability, laden/unladen

%

15/15

15/15

15/15
