EFL502/702/802/1002

Performance

●Hydraulic steering system makes operation easier and more flexible and strong steering axle, more

suitable for harsh working conditions；

●High travelling, lifting speed and maximum gradeability.

Operation

●The wide-view mast design ensures that the operator has an excellent field of vision during operation；

●Great ergonomic design with large leg-room, adjustable steering wheel and comfortable seat；

●Optional dual charger, faster and more convenient.

Safety

●Low noise and low vibration are good for the health of operator and 0 emissions,

clean and green, protecting the environment；

●Strengthen forks to transport goods more stably and safely

Maintenance

●Maintenance-free lithium battery greatly reduces maintenance costs；

●Equipped with BMS consist of a master controller and two auxilliary controllers, it can reduce the risk

of truck downtime due to battery failure. The battery instrument will have fault code for easier maintenance.

Specifications

Model

EFL502

EFL702

EFL802

EFL1002

Power type

full electric

full electric

full electric

full electric

Operation

Seated

Seated

Seated

Seated

Capacity

Q(kg)

5000

7000

8000

10000

Loading center

C(mm)

600

600

600

600

Lifting height

h3 (mm)

3000

3000

3000

3000

Height of overhead guard

h6 (mm)

2450

2450

2560

2560

Seat height/standing height

h7 (mm)

1390

1390

1450

1450

Tow coupling height

h10 (mm)

310

310

524

524

Overall length

l1 (mm)

4735

4745

5730

5730

Length to face of fork

l2 (mm)

3515

3525

4210

4210

Overall width

b1/b2 (mm)

1994

1994

2242

2242

Travel speed, laden/unladen

km/h

12/14

14/16

14/16

14/16

Lifting speed, laden/unladen

m/s

0.25/0.3

0.35/0.4

0.28/0.32

0.28/0.32

Lowering speed, laden/ unladen

m/s

0.4/0.38

0.4/0.38

0.45/0.4

0.45/0.4

Max.Drawbar pull  (laden)

N

26000

30000

30000

32000

Gradeability, laden/unladen

%

14/15

15/20

15/16
