EFL803/1003-(HV)-6/9
WARRANTY
SERVICE
DELIVERY
TERMS
SOLUTION
●Capacity：8/10t
●Heavy Duty Electric Forklift
●Strong heat dissipation capability
●Strong power and climbing ability
●Battery heating function
●High voltage(309V) available
Performance
●Battery heating function when charging, stable and continuous charging even in cold weather,
ensuring work efficiency；
●Mast lifting and lowering buffer, more stable and safety, protect the goods；
●A variety of configurations are available for different working conditions.
Operation
●Fork positioner with pin type forks, more precise operation, improved work efficiency；
●Suspension seat with OPS, avoid accidents by misoperation and more comfortable operation；
●Equipped with LED light, and adjustable steering wheel, easy to operate.
Safety
●Back handle with horn button and reversing buzzer, remind people around to avoid accidents；
●Fire extinguisher holder, can install fire extinguisher, ensure the safety of operators and cargo；
●Strengthen the roof guard, firm and stable.
Maintenance
●LCD display, display power, working hours, and faults, etc., for easy maintenance；
●Lithium battery, maintenance-free；
●Equip with reliable components, enable the forklift with minimum error rate.
Specifications
Model |
EFL803-6 |
EFL803-HV-6 |
EFL803-9 |
EFL803-HV-9 |
EFL1003-6 |
EFL1003-HV-6 |
|
Power type |
full electric |
full electric |
full electric |
full electric |
full electric |
full electric |
|
Operation |
Seated |
Seated |
Seated |
Seated |
Seated |
Seated |
|
Capacity |
Q(kg) |
8000 |
8000 |
8000 |
8000 |
10000 |
10000 |
Loading center |
C(mm) |
600 |
600 |
900 |
900 |
600 |
600 |
Lifting height |
h3 (mm) |
3000 |
3000 |
3000 |
3000 |
3000 |
3000 |
Height of overhead guard |
h6 (mm) |
2680 |
2680 |
2680 |
2680 |
2680 |
2680 |
Seat height/standing height |
h7 (mm) |
1550 |
1550 |
1550 |
1550 |
1550 |
1550 |
Tow coupling height |
h10 (mm) |
630 |
630 |
630 |
630 |
630 |
630 |
Overall length |
l1 (mm) |
5475 |
5475 |
5785 |
5785 |
5480 |
5480 |
Length to face of fork |
l2 (mm) |
3955 |
3955 |
3965 |
3965 |
3960 |
3960 |
Overall width |
b1/b2 (mm) |
2200 |
2200 |
2200 |
2200 |
2200 |
2200 |
Travel speed, laden/unladen |
km/h |
13/15 |
29/30 |
13/15 |
29/30 |
13/15 |
29/30 |
Lifting speed, laden/unladen |
m/s |
0.32/0.40 |
0.39/0.47 |
0.32/0.40 |
0.39/0.47 |
0.32/0.4 |
0.39/0.47 |
Lowering speed, laden/ unladen |
m/s |
0.46/0.4 |
0.46/0.4 |
0.46/0.4 |
0.46/0.4 |
0.46/0.4 |
0.46/0.4 |
Gradeability, laden/unladen |
% |
13/16 |
22/30 |
13/16 |
22/30 |
13/16 |
22/30 |
