EFS101

Performance

●Compact design, lighter and smaller, which is particularly beneficial for operating in narrow

spaces. It can enter and exit elevators, improving the utilization rate of storage space;

●Electronic steering, flexible steering, easy and effortless operation.

Operation

●Rear-wheel drive, smaller turning radius, easy operation, truly giving full play to the structural

advantages of the 3-wheel;

●Integrated joystick makes control easier;

●Integrated charger, which offers operators convenience and flexibility in daily usage.

Safety

●Compared with ordinary forklifts of the same tonnage, it has a higher ground clearance and can drive

smoothly on uneven roads;

●Due to the ergonomic foot pedal design, operators can get on and off the vehicle easily and safely.

Maintenance

●Large capacity maintenance-free battery, greatly improving battery life;

●Adopt reliable components that have been tested in the market to ensure its long service life.

Specifications

Model

EFS101

Power type

full electric

Operation

Steated

Capacity

Q(kg)

990

Loading center

C(mm)

400

Lifting height

h3 (mm)

3000

Height of overhead guard

h6 (mm)

1988

Seat height/standing height

h7 (mm)

878

Overall length

l1 (mm)

2402

Length to face of fork

l2 (mm)

1482

Overall width

b1/b2 (mm)

894

Travel speed, laden/unladen

km/h

6/8

Lifting speed, laden/unladen

m/s

0.13/0.2

Lowering speed, laden/ unladen

m/s

0.16/0.15

Gradeability, laden/unladen

%

3/5
