EFX2-251

Performance

●Proportional lifting system for more precise operation；

●OPS system, the driver cannot operate when leaving the seat (Optional)；

●The full cabin meet different weather needs (Optional).

Operation

●External plug, convenient for charging on time；

●Equipped with adjustable steering wheels, spacious legroom and suspended seat,comfortable

operation and reducing operator fatigue；

●Equipped with LED lights, providing better and safer night vision.

Safety

●Explosion-proof design for hydraulic system, even if the oil pipe bursts, the mast will not

descend quickly；

●Automatic deceleration function for turning, safe and reliable；

●Fork descent buffering function ensures smooth lifting and lowering, reduces vibration, and

protects goods.

Maintenance

●Lithium battery, maintenance-free, environment-friendly；

●The controller is integrated layout for easy maintenance；

●Waterproof connectors and instruments extend service life.

Specifications

Model

EFX2-251

Power type

full electric

Operation

Seated

Capacity

Q(kg)

2500

Loading center

C(mm)

500

Lifting height

h3 (mm)

3000

Height of overhead guard

h6 (mm)

2170

Seat height/standing height

h7 (mm)

1110

Tow coupling height

h10 (mm)

295

Overall length

l1 (mm)

3598

Length to face of fork

l2 (mm)

2528

Overall width

b1/b2 (mm)

1154

Travel speed, laden/unladen

km/h

11/12

Lifting speed, laden/unladen

m/s

0.29/0.36

Lowering speed, laden/ unladen

m/s

0.4/0.43

Gradeability, laden/unladen

%

15/16
