Electric Order Picker

WARRANTY

SERVICE

DELIVERY

TERMS

SOLUTION
●Independently designed and developed
●Ideal for multi-level rack order picking
●Durable and robust construction
●Advanced control system
●Full-height travel capability
Performance
●Proportional control system, offers smooth and precise control over lifting, lowering, and movement for
enhanced operational accuracy
●Charging protection system, safeguards the battery during charging to extend battery life
●Tilt protection system, automatically restricts operation if the vehicle tilts beyond safe angle, preventing tip-overs
●LED light ensures clear visibility and safe operation in low-light warehouse environments
Operation
●Ergonomic integrated control handle, designed for easy and intuitive operation, reducing operator fatigue
●Full-height travel capability, enables the vehicle to move at all heights, improving efficiency during tasks
●Equipped with storage rack, convenient and organized cargo loading and transportation
●Small turning radius,allowing for highly flexible operation even in tight warehouse spaces
Safety
●Platform self-locking door, automatically locks when elevated to secure the operator and prevent accidental access
●Emergency lowering system, allows safe descent of the platform in case of power loss or malfunction
●Pressure relief valve, prevents hydraulic system overload, protecting both vehicle and operator
●Sturdy guardrails provides strong protection around the platform, enhancing operator safety
Maintenance
●Fault diagnosis system, quickly identifies and alerts operators to potential issues, simplifying maintenance
●Proven and market-tested components to minimize maintenance costs and enhance overall reliability
●Designed with waterproof electrical connectors that protect the circuit system from moisture and dust, extending the
vehicle’s service life
Specifications
Max. Platform height |
mm |
3000 |
4000 |
Working height |
mm |
4125 |
5125 |
Overall length |
mm |
1480 |
1480 |
Overall width |
mm |
756 |
756 |
Overall height |
mm |
1475 |
1805 |
Platform capacity |
kg |
150 |
150 |
Cargo platform capacity |
kg |
90 |
90 |
Ground clearance |
mm |
15 |
15 |
Service weight |
kg |
840 |
870 |
Battery |
V/Ah |
2x12/100 |
2x12/100 |
