Semi-Electric Order Picker

Semi-Electric Order Picker

We provide
WARRANTY
We guarantee
SERVICE
Fast
DELIVERY
Transparent
TERMS
Customized
SOLUTION

●Lightweight design

●Smooth lifting/lowering

●Simple operation

●With multi-tiered shelving systems

●Cost-Effectiveness

Category:

Performance

● Cost-Effectiveness – Designed to deliver high performance and durability at an economical price,

providing excellent value for your investment

● Advanced Charging Protection – Features an intelligent battery management system to prevent overcharging

and extend battery life

● Self-Locking Platform Gate – Ensures operator safety by automatically locking during operation, preventing

accidental openings

● Emergency Descent System – Allows for safe and controlled lowering in case of power loss or unexpected shutdowns

● Emergency Stop Button – Provides instant braking in critical situations for enhanced operational safety

● Four-Point Braking System – Delivers superior stability during lifting and lowering by firmly securing the vehicle in place

● Centralized Functional Layout – Intuitive and user-friendly control panel designed for easy and efficient operation

● Safety Guardrails & Battery Indicator – Includes protective guardrails to prevent falls and a clear battery level display

for timely recharging, ensuring both safety and battery health



Specifications

Max. Platform height
mm
2700
3300
4000
4500
Maximum machine height
mm
4020
4900
5360
6050
Ground clearance
mm
30
30
30
30
Capacity
kg
200
200
200
200
Overall length
mm
1320
1320
1320
1320
Overall width
mm
850
850
850
850
Overall height
mm
1760
2040
1830
2000
Service weight
kg
270
320
380
420
Battery
V/Ah
12/135
12/135
12/135
12/135
