Semi-Electric Order Picker

WARRANTY

SERVICE

DELIVERY

TERMS

SOLUTION
●Lightweight design
●Smooth lifting/lowering
●Simple operation
●With multi-tiered shelving systems
●Cost-Effectiveness
Performance
● Cost-Effectiveness – Designed to deliver high performance and durability at an economical price,
providing excellent value for your investment
● Advanced Charging Protection – Features an intelligent battery management system to prevent overcharging
and extend battery life
● Self-Locking Platform Gate – Ensures operator safety by automatically locking during operation, preventing
accidental openings
● Emergency Descent System – Allows for safe and controlled lowering in case of power loss or unexpected shutdowns
● Emergency Stop Button – Provides instant braking in critical situations for enhanced operational safety
● Four-Point Braking System – Delivers superior stability during lifting and lowering by firmly securing the vehicle in place
● Centralized Functional Layout – Intuitive and user-friendly control panel designed for easy and efficient operation
● Safety Guardrails & Battery Indicator – Includes protective guardrails to prevent falls and a clear battery level display
for timely recharging, ensuring both safety and battery health
Specifications
Max. Platform height |
mm |
2700 |
3300 |
4000 |
4500 |
Maximum machine height |
mm |
4020 |
4900 |
5360 |
6050 |
Ground clearance |
mm |
30 |
30 |
30 |
30 |
Capacity |
kg |
200 |
200 |
200 |
200 |
Overall length |
mm |
1320 |
1320 |
1320 |
1320 |
Overall width |
mm |
850 |
850 |
850 |
850 |
Overall height |
mm |
1760 |
2040 |
1830 |
2000 |
Service weight |
kg |
270 |
320 |
380 |
420 |
Battery |
V/Ah |
12/135 |
12/135 |
12/135 |
12/135 |
